KAYO TT190-R Pitbike
An upgraded variant of the KAYO TT190 with more bang for your buck!
Performance Highlights
Product Overview
An upgraded variant of the KAYO TT190 with more bang for your buck!
ENGINE
Engine
ZS190, 4-Stroke, Air Cooled
Valves
SOHC, 2 valve
Displacement
187.2cc
Bore x Stroke
62.0 x 62.0mm
Compression Ratio
11.0:1
Fuel System
Carburetor
Maximum Power
12 kw @ 9500rpm
Maximum Torque
13 Nm @ 8000rpmm
Clutch
Wet, 5 disc
Ignition
CDI
Final Drive
428 chain
CHASSIS
Frame Design
Cradle frame
Rear Subframe Design
Steel subframe
Swing Arm
Alloy 410mm
Footpegs
Pro
Handlebar
Steel
Exhaust
KAYO Performance
Silencer
KAYO Performance
Front Suspension
FAST ACE 730mm Adjustable
Rear Suspension
DNM 360mm Adjustable
Front Rim
Steel 17×1.6
Rear Rim
Steel 14×2.15
Rim Lock
Front & rear
Front Tyres
70/100-17
Rear Tyres
90/100-14
Front Brake
Dual piston – Ø210 mm disc
Rear Brake
Single piston – Ø200 mm disc
DIMS & CAPACITY
Length
1765mm
Width
770mm
Height
1100mm
Wheelbase
1220mm
Ground Clearance
280mm
Seat Height
850mm
Dry Weight
81.0kg
Fuel Capacity
5.5 litres
Packing Size LWH
1560 x 380 x 735mm
Technical Specifications
| Brand | Surron |
|---|---|
| SKU Identifier | SR-KAYO-TT190-6910 |
| Motor Architecture | 12 Kw @ 9500Rpm |
| Warranty Term | 2 Years Limited Warranty |
